Height Field Simulation on GPU

The code below shows a first rough implementation of a height field simulation on GPU. It was an experiment to test different approaches to perform calculations on the GPU; this one uses plain textures from which we read the current values and another set of textures into which the new results are written.

The height field algorithm diffuses a certain value In my case I used this value as height. On the CPU this looks something like the code below. We need two arrays, one array float u0[FIELD_NN] that contains the current heights, and another one float u1[FIELD_NN] into which we write the changed values using the current velocity array (float v[FIELD_NN]). After traversing all the cells in the grid, we copy the new values from u1 into u0 so the newest values will be used during the next iteration.

The value of c needs to be in a certain range if you want to get good results, see the height field slides from the link above.

Download the code here. Tested only on a mac 10.9.

Height Field on CPU

void Water::updateHeightField(float dt) {
  float c = 1.0;
  float max_c = (1.0 / dt);
  if(c > max_c) {
    printf("Warning: invalid C value\n");
    return;
  }

  dt = dt * 4.9;
  for(int j = 1; j < FIELD_N - 1; ++j) {
    for(int i = 1; i < FIELD_N - 1; ++i) {
      int current = ((j + 0) * FIELD_N) + (i + 0);
      int right   = ((j + 0) * FIELD_N) + (i + 1);
      int left    = ((j + 0) * FIELD_N) + (i - 1);
      int top     = ((j + 1) * FIELD_N) + (i + 0);
      int bottom  = ((j - 1) * FIELD_N) + (i + 0);
      float f = ((c*c) * ((u0[right] + u0[left] + u0[bottom] + u0[top])) - (4.0 * u0[current])) / 4.0 ;
      if(f > 0.1) {
        f = 0.1;
      }
      else if(f < -0.1) {
        f = -0.1;
      }

      v[current] = v[current] + f * dt;
      u1[current] = u0[current] + v[current] * dt;
      v[current] *= 0.995;

    }
  }
  memcpy(u0, u1, sizeof(u0));
}

On the GPU, we need to ping/pong between the source values and the destination values for both the height values and the velocity values, so we need 4 textures for those two values. In the code below I also have a texture into which we write the normals that we calculate in a separate step.

HeightField.h

/*

  HeightField
  -----------

  This class implements a basic height field diffusion as described in
  http://www.matthiasmueller.info/talks/gdc2008.pdf

  We perform the following steps:

  - Diffuse the current height values according to some
    velocity. We use u0 and u1 as the height values. We need two
    because we're ping/ponging the values. The current velocity
    at which the height field diffuses is stored in v0 and v1.
    After each time step we change `state_diffuse` which toggles
    the reading/writing from u0/v0 and u1/v1.

  - Once we've done the diffuse step, we perform a processing step
    where we calculate the world position of the heightfield. These
    height values are stored in `tex_out_pos`.

  - When we have the positions in `tex_out_pos` we perform on more
    step where we calculate the normals, and values we might need for
    water rendering.

  - To render the height field you can use `vertices_vbo` and `vertices_vao`.
    They are setup in such a way that you'll get one in attribute in your shader
    called `tex` which contains the row/column into the position texture. Use this
    to set gl_Position.

  Things to know / improve:

  - We're not reusing the attribute less GL_VERTEX_SHADER;

  - You can use the vertices_vao/vbo to render the height field, see the
    debug shaders.

 */
#ifndef ROXLU_HEIGHT_FIELD_H
#define ROXLU_HEIGHT_FIELD_H

#define ROXLU_USE_ALL
#include <tinylib.h>
#include <vector>

struct HeightFieldVertex {
  HeightFieldVertex(vec2 texcoord):tex(texcoord){}
  HeightFieldVertex(){}
  vec2 tex;
};

class HeightField {

 public:
  HeightField();
  bool setup(int w, int h);
  void update(float dt);     /* diffuses the height field */
  void process();            /* processes the current values, calculates normals, create position texture etc.. */
  void debugDraw();

  void print();               /* print some debug info */

 private:
  bool setupDiffusing();     /* setup GL state for the diffusion step */
  bool setupProcessing();    /* setup GL state for the processing step; calculates normals, positions, texcoord etc.. using the current field values */
  bool setupDebug();         /* setup GL state for debugging */
  bool setupVertices();      /* create the triangle mesh (or the order of vertices, position is extracted from the position texture) */

 public:

  /* diffusion of height field */
  GLuint field_fbo;
  GLuint tex_u0;              /* height value */
  GLuint tex_u1;              /* height value */
  GLuint tex_v0;              /* velocity at which u diffuses */
  GLuint tex_v1;              /* velocity at which u diffuses */
  GLint u_dt;                 /* reference to our dt uniform */
  GLuint field_vao;           /* we need a vao to render attribute less vertices */
  Program field_prog;         /* this program does the diffuse step */
  int state_diffuse;          /* toggles between 0 and 1 to ping/pong the diffuse/vel textures */

  /* general info */
  int field_size;             /* the size of our rectangular height field */
  int win_w;                  /* window width, use to reset the viewport */
  int win_h;                  /* window height, used to reset the viewport */

  /* used to process the height field and extract some usefull data */
  GLuint process_fbo;         /* we use a separate FBO to perform the processing step so we have some space for extra attachments */
  GLuint tex_out_norm;        /* the GL_RGB32F texture that will keep our calculated normals */
  GLuint tex_out_pos;         /* the GL_RGB32F texture that will keep our positions */
  GLuint tex_out_texcoord;    /* the GL_RG32F texture that will keep our texcoords */
  Program process_prog;       /* the program we use to calculate things like normals, etc.. */
  Program pos_prog;           /* the program we use to calculate the positions */

  /* used to debug draw */
  Program debug_prog;         /* debug shaders, shows how to set gl_Position */
  mat4 pm;                    /* projection matrix */
  mat4 vm;                    /* view matrix */

  /* vertices */
  std::vector<HeightFieldVertex> vertices;    /* The vertices that you can use to render a triangular height field, see the debug shader */
  GLuint vertices_vbo;                        /* VBO that holds the HeightFieldVertex data that forms the height field triangular grid */
  GLuint vertices_vao;                        /* The VAO to draw the height field vertices */
};

#endif

HeightField.cpp

#include "HeightField.h"

HeightField::HeightField()
  :field_fbo(0)
  ,tex_u0(0)
  ,tex_u1(0)
  ,tex_v0(0)
  ,tex_v1(0)
  ,field_size(128)
  ,field_vao(0)
  ,state_diffuse(0)
  ,win_w(0)
  ,win_h(0)
  ,process_fbo(0)
  ,tex_out_norm(0)
  ,tex_out_pos(0)
  ,tex_out_texcoord(0)
  ,vertices_vbo(0)
  ,vertices_vao(0)
{
}

bool HeightField::setup(int w, int h) {

  if(!w || !h) {
    printf("Error: invalid width/height: %d x %d\n", w, h);
    return false;
  }

  win_w = w;
  win_h = h;

  glGenVertexArrays(1, &field_vao);

  if(!setupDiffusing()) {
    printf("Error: cannot set GL state for the diffuse step.\n");
    return false;
  }

  if(!setupProcessing()) {
    printf("Error: cannot setup the GL state for the processing.\n");
    return false;
  }

  if(!setupVertices()) {
    printf("Error: cannot setup the vertices for the height field.\n");
    return false;
  }

  if(!setupDebug()) {
    printf("Error: cannot setup the GL state for debugging.\n");
    return false;
  }

  return true;
}

bool HeightField::setupVertices() {
  glGenVertexArrays(1, &vertices_vao);
  glBindVertexArray(vertices_vao);

  glGenBuffers(1, &vertices_vbo);
  glBindBuffer(GL_ARRAY_BUFFER, vertices_vbo);

  std::vector<HeightFieldVertex> tmp(field_size * field_size, HeightFieldVertex());
  for(int j = 0; j < field_size; ++j) {
    for(int i = 0; i < field_size; ++i) {
      int dx = j * field_size + i;
      tmp[dx].tex.set(i, j);
    }
  }

  for(int j = 0; j < field_size-1; ++j) {
    for(int i = 0; i < field_size-1; ++i) {
      int a = (j + 0) * field_size + (i + 0);
      int b = (j + 0) * field_size + (i + 1);
      int c = (j + 1) * field_size + (i + 1);
      int d = (j + 1) * field_size + (i + 0);
      vertices.push_back(tmp[a]);
      vertices.push_back(tmp[b]);
      vertices.push_back(tmp[c]);

      vertices.push_back(tmp[a]);
      vertices.push_back(tmp[c]);
      vertices.push_back(tmp[d]);
    }
  }

  glBufferData(GL_ARRAY_BUFFER, sizeof(HeightFieldVertex) * vertices.size(), vertices[0].tex.ptr(), GL_STATIC_DRAW);

  glEnableVertexAttribArray(0); // tex
  glVertexAttribPointer(0, 2, GL_FLOAT, GL_FALSE, sizeof(HeightFieldVertex), (GLvoid*)0);
  return true;
}

bool HeightField::setupDebug() {

  pm.perspective(60.0f, float(win_w)/win_h, 0.01f, 100.0f);
  //vm.lookAt(vec3(0.0f, 35.0f, 0.0f), vec3(0.0f, 0.0f, 0.1f), vec3(0.0f, 1.0f, 0.0f));
  vm.translate(0.0f, 0.0f, -30.0f);
  vm.rotateX(30 * DEG_TO_RAD);

  const char* atts[] = { "a_tex" };
  debug_prog.create(GL_VERTEX_SHADER, rx_to_data_path("height_field_debug.vert"));
  debug_prog.create(GL_FRAGMENT_SHADER, rx_to_data_path("height_field_debug.frag"));
  debug_prog.link(1, atts);

  glUseProgram(debug_prog.id);
  glUniformMatrix4fv(glGetUniformLocation(debug_prog.id, "u_pm"), 1, GL_FALSE, pm.ptr());
  glUniformMatrix4fv(glGetUniformLocation(debug_prog.id, "u_vm"), 1, GL_FALSE, vm.ptr());
  glUniform1i(glGetUniformLocation(debug_prog.id, "u_pos_tex"), 0);

  return true;
}

bool HeightField::setupProcessing() {

  glGenTextures(1, &tex_out_norm);
  glBindTexture(GL_TEXTURE_2D, tex_out_norm);
  glTexImage2D(GL_TEXTURE_2D, 0, GL_RGB32F, field_size, field_size, 0, GL_RGB, GL_FLOAT, 0);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_NEAREST);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_NEAREST);

  glGenTextures(1, &tex_out_pos);
  glBindTexture(GL_TEXTURE_2D, tex_out_pos);
  glTexImage2D(GL_TEXTURE_2D, 0, GL_RGB32F,field_size, field_size, 0, GL_RGB, GL_FLOAT, 0);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_NEAREST);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_NEAREST);

  glGenTextures(1, &tex_out_texcoord);
  glBindTexture(GL_TEXTURE_2D, tex_out_texcoord);
  glTexImage2D(GL_TEXTURE_2D, 0, GL_RG32F, field_size, field_size, 0, GL_RG, GL_FLOAT, 0);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_NEAREST);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_NEAREST);

  glGenFramebuffers(1, &process_fbo);
  glBindFramebuffer(GL_FRAMEBUFFER, process_fbo);

  glFramebufferTexture2D(GL_FRAMEBUFFER, GL_COLOR_ATTACHMENT0, GL_TEXTURE_2D, tex_out_pos, 0);
  glFramebufferTexture2D(GL_FRAMEBUFFER, GL_COLOR_ATTACHMENT1, GL_TEXTURE_2D, tex_out_norm, 0);
  glFramebufferTexture2D(GL_FRAMEBUFFER, GL_COLOR_ATTACHMENT2, GL_TEXTURE_2D, tex_out_texcoord, 0);

  if(glCheckFramebufferStatus(GL_FRAMEBUFFER) != GL_FRAMEBUFFER_COMPLETE) {
    printf("Error: process framebuffer not complete.\n");
    return false;
  }

  // Position processing
  const char* pos_frags[] = { "out_pos" };
  pos_prog.create(GL_VERTEX_SHADER, rx_to_data_path("height_field.vert"));
  pos_prog.create(GL_FRAGMENT_SHADER, rx_to_data_path("height_field_pos.frag"));
  pos_prog.link(0, NULL, 1, pos_frags);
  glUseProgram(pos_prog.id);
  glUniform1i(glGetUniformLocation(pos_prog.id, "u_height_tex"), 0);
  glUniform1i(glGetUniformLocation(pos_prog.id, "u_vel_tex"), 1);


  // Extra processing
  const char* process_frags[] = { "out_norm", "out_tex" };
  process_prog.create(GL_VERTEX_SHADER, rx_to_data_path("height_field.vert"));
  process_prog.create(GL_FRAGMENT_SHADER, rx_to_data_path("height_field_process.frag"));
  process_prog.link(0, NULL, 2, process_frags);
  glUseProgram(process_prog.id);
  glUniform1i(glGetUniformLocation(process_prog.id, "u_height_tex"), 0);
  glUniform1i(glGetUniformLocation(process_prog.id, "u_vel_tex"), 1);
  glUniform1i(glGetUniformLocation(process_prog.id, "u_pos_tex"), 2);

  glBindFramebuffer(GL_FRAMEBUFFER, 0);

  return true;
}

bool HeightField::setupDiffusing() {

  // some text data
  float* u = new float[field_size * field_size];
  float* v = new float[field_size * field_size];
  int upper = 50;
  int lower = 30;
  for(int j = 0; j < field_size; ++j) {
    for(int i = 0; i < field_size; ++i) {
      u[j * field_size + i] = 0.0f;
      v[j * field_size + i] = 0.0f;
      if(i > lower && i < upper && j > lower && j < upper) {
        u[j * field_size + i] = 3.5;
      }
    }
  }

  glGenTextures(1, &tex_u0);
  glBindTexture(GL_TEXTURE_2D, tex_u0);
  glTexImage2D(GL_TEXTURE_2D, 0, GL_R32F, field_size, field_size, 0, GL_RED, GL_FLOAT, u);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_NEAREST);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_NEAREST);

  glGenTextures(1, &tex_u1);
  glBindTexture(GL_TEXTURE_2D, tex_u1);
  glTexImage2D(GL_TEXTURE_2D, 0, GL_R32F, field_size, field_size, 0, GL_RED, GL_FLOAT, u);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_NEAREST);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_NEAREST);

  glGenTextures(1, &tex_v0);
  glBindTexture(GL_TEXTURE_2D, tex_v0);
  glTexImage2D(GL_TEXTURE_2D, 0, GL_R32F, field_size, field_size, 0, GL_RED, GL_FLOAT, v);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_NEAREST);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_NEAREST);

  glGenTextures(1, &tex_v1);
  glBindTexture(GL_TEXTURE_2D, tex_v1);
  glTexImage2D(GL_TEXTURE_2D, 0, GL_R32F, field_size, field_size, 0, GL_RED, GL_FLOAT, v);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_NEAREST);
  glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_NEAREST);


  glGenFramebuffers(1, &field_fbo);
  glBindFramebuffer(GL_FRAMEBUFFER, field_fbo);
  glFramebufferTexture2D(GL_FRAMEBUFFER, GL_COLOR_ATTACHMENT0, GL_TEXTURE_2D, tex_u0, 0);
  glFramebufferTexture2D(GL_FRAMEBUFFER, GL_COLOR_ATTACHMENT1, GL_TEXTURE_2D, tex_u1, 0);
  glFramebufferTexture2D(GL_FRAMEBUFFER, GL_COLOR_ATTACHMENT2, GL_TEXTURE_2D, tex_v0, 0);
  glFramebufferTexture2D(GL_FRAMEBUFFER, GL_COLOR_ATTACHMENT3, GL_TEXTURE_2D, tex_v1, 0);

  if(glCheckFramebufferStatus(GL_FRAMEBUFFER) != GL_FRAMEBUFFER_COMPLETE) {
    printf("Error: diffuse framebuffer not complete.\n");
    return false;
  }

  const char* frags[] = { "out_height", "out_vel" } ;
  field_prog.create(GL_VERTEX_SHADER, rx_to_data_path("height_field.vert"));
  field_prog.create(GL_FRAGMENT_SHADER, rx_to_data_path("height_field.frag"));
  field_prog.link(0, NULL, 2, frags);

  glUseProgram(field_prog.id);
  glUniform1i(glGetUniformLocation(field_prog.id, "u_height_tex"), 0);
  glUniform1i(glGetUniformLocation(field_prog.id, "u_vel_tex"), 1);
  u_dt = glGetUniformLocation(field_prog.id, "u_dt");

  glBindFramebuffer(GL_FRAMEBUFFER, 0);

  delete[] v;
  delete[] u;
  u = NULL;
  v = NULL;
  return true;
}

void HeightField::update(float dt) {
  glDisable(GL_DEPTH_TEST);
  glDisable(GL_BLEND);

  glViewport(0, 0, field_size, field_size);
  glBindFramebuffer(GL_FRAMEBUFFER, field_fbo);
  glUseProgram(field_prog.id);
  glBindVertexArray(field_vao);
  glUniform1f(u_dt, dt);

  state_diffuse = 1 - state_diffuse;

  if(state_diffuse == 0) {
    // read from u0, write to u1
    // read from v0, write to v1
    GLenum drawbufs[] = { GL_COLOR_ATTACHMENT1, GL_COLOR_ATTACHMENT3 };
    glDrawBuffers(1, drawbufs);

    glActiveTexture(GL_TEXTURE0);  glBindTexture(GL_TEXTURE_2D, tex_u0);
    glActiveTexture(GL_TEXTURE2);  glBindTexture(GL_TEXTURE_2D, tex_v0);

    glDrawArrays(GL_TRIANGLE_STRIP, 0, 4);
  }
  else {
    // read from u1, write to u0
    // read from v1, write to v0
    GLenum drawbufs[] = { GL_COLOR_ATTACHMENT0, GL_COLOR_ATTACHMENT2 };
    glDrawBuffers(2, drawbufs);

    glActiveTexture(GL_TEXTURE0);  glBindTexture(GL_TEXTURE_2D, tex_u1);
    glActiveTexture(GL_TEXTURE3);  glBindTexture(GL_TEXTURE_2D, tex_v1);
    glDrawArrays(GL_TRIANGLE_STRIP, 0, 4);
  }

  glBindFramebuffer(GL_FRAMEBUFFER, 0);
  glViewport(0, 0, win_w, win_h);
}

void HeightField::process() {
  glBindFramebuffer(GL_FRAMEBUFFER, process_fbo);
  glViewport(0, 0, field_size, field_size);
  glBindVertexArray(field_vao);

  glActiveTexture(GL_TEXTURE0); glBindTexture(GL_TEXTURE_2D, tex_u0);
  glActiveTexture(GL_TEXTURE1); glBindTexture(GL_TEXTURE_2D, tex_v0);

  {
    // Calculate positions.
    glUseProgram(pos_prog.id);

    GLenum drawbufs[] = { GL_COLOR_ATTACHMENT0 } ; // , GL_COLOR_ATTACHMENT1, GL_COLOR_ATTACHMENT2 } ;
    glDrawBuffers(1, drawbufs);
    glDrawArrays(GL_TRIANGLE_STRIP, 0, 4);
  }

  {
    // Use positions to calc normals, etc..
    glUseProgram(process_prog.id);
    GLenum drawbufs[] = { GL_COLOR_ATTACHMENT1, GL_COLOR_ATTACHMENT2 };
    glDrawBuffers(2, drawbufs);

    glActiveTexture(GL_TEXTURE2);
    glBindTexture(GL_TEXTURE_2D, tex_out_pos);

    glDrawArrays(GL_TRIANGLE_STRIP, 0, 4);
  }

  glBindFramebuffer(GL_FRAMEBUFFER, 0);
}

void HeightField::debugDraw() {
  glViewport(0, 0, win_w, win_h);
  glBindFramebuffer(GL_FRAMEBUFFER, 0); // tmp
  glDisable(GL_DEPTH_TEST);

  glBindVertexArray(vertices_vao);
  glUseProgram(debug_prog.id);

  glActiveTexture(GL_TEXTURE0);
  glBindTexture(GL_TEXTURE_2D, tex_out_pos);

  glPolygonMode(GL_FRONT_AND_BACK, GL_LINE);
  //glDrawArrays(GL_TRIANGLES, 0, vertices.size());
  glDrawArrays(GL_POINTS, 0, vertices.size());
  glPolygonMode(GL_FRONT_AND_BACK, GL_FILL);

#if 1
  glBindFramebuffer(GL_READ_FRAMEBUFFER, field_fbo);
  glBindFramebuffer(GL_DRAW_FRAMEBUFFER, 0);
  glReadBuffer(GL_COLOR_ATTACHMENT0);
  glBlitFramebuffer(0, 0, field_size, field_size, 0, 0, field_size, field_size, GL_COLOR_BUFFER_BIT, GL_LINEAR);
#endif
}


void HeightField::print() {
  printf("heightfield.tex_u0: %d\n", tex_u0);
  printf("heightfield.tex_u1: %d\n", tex_u1);
  printf("heightfield.tex_v0: %d\n", tex_v0);
  printf("heightfield.tex_v1: %d\n", tex_v1);
  printf("heightfield.tex_out_norm: %d\n", tex_out_norm);
  printf("heightfield.tex_out_texcoord: %d\n", tex_out_texcoord);
  printf("heightfield.tex_out_pos: %d\n", tex_out_pos);
}

height_field.vert

#version 150

const vec2[] pos = vec2[4](
  vec2(-1.0, 1.0),
  vec2(-1.0, -1.0),
  vec2(1.0, 1.0),
  vec2(1.0, -1.0)
);

const vec2[] tex = vec2[4](
  vec2(0.0, 1.0),
  vec2(0.0, 0.0),
  vec2(1.0, 1.0),
  vec2(1.0, 0.0)
);

out vec2 v_tex;

void main() {
  gl_Position = vec4(pos[gl_VertexID], 0.0, 1.0);
  v_tex = tex[gl_VertexID];
}

height_field.frag

/*

  Height Field Water Simulation
  -----------------------------
  - See http://www.matthiasmueller.info/talks/gdc2008.pdf
  - The value of c must be limited to: 1.0/dt, so 30fps, 1.0/0.033 = 33.33.

 */

#version 150

uniform sampler2D u_height_tex;
uniform sampler2D u_vel_tex;
uniform float u_dt;
out float out_height;
out float out_vel;
in vec2 v_tex;

void main() {

  float u        = texture(u_height_tex, v_tex).r;
  float u_right  = textureOffset(u_height_tex, v_tex, ivec2( 1.0,  0.0)).r;
  float u_left   = textureOffset(u_height_tex, v_tex, ivec2(-1.0,  0.0)).r;
  float u_top    = textureOffset(u_height_tex, v_tex, ivec2( 0.0, -1.0)).r;
  float u_bottom = textureOffset(u_height_tex, v_tex, ivec2( 0.0,  1.0)).r;

  float c = 50.0;
  float f = ((c*c) * ((u_right + u_left + u_top + u_bottom) - (4.0 * u)) ) / 4.0;

  float v = texture(u_vel_tex, v_tex).r + f * u_dt;
  out_height = u + v * u_dt;
  out_vel = v * 0.996;
}

height_field_debug.vert

#version 150

in vec2 a_tex;
uniform mat4 u_pm;
uniform mat4 u_vm;
uniform sampler2D u_pos_tex;

void main() {
  vec4 world_pos = vec4(texelFetch(u_pos_tex, ivec2(a_tex), 0).rgb, 1.0);
  gl_Position = u_pm * u_vm * world_pos;
}

height_field_debug.frag

#version 150

out vec4 fragcolor;

void main() {
  fragcolor = vec4(1.0, 0.0, 0.0, 1.0);
}

height_field_pos.frag

#version 150

uniform sampler2D u_height_tex;
uniform sampler2D u_vel_tex;
out vec3 out_pos;
in vec2 v_tex;

const float size_x = 35.0;
const float size_y = 35.0;
const float field_size = 128.0;
const float half_x = size_x * 0.5;
const float half_y = size_y * 0.5;

void main() {
  float u = texture(u_height_tex,v_tex).r;
  out_pos = vec3(-half_x + (v_tex.s * size_x),
                  u,
                 -half_y + (v_tex.t * size_y));
}

height_field_process.frag

/*

  - Uses the calculated position to calculate the height values.
  - I'm not sure is I need to calculate dx/dy using a stepsize of 2 or 1

 */
#version 150

uniform sampler2D u_pos_tex;
uniform sampler2D u_height_tex;
uniform sampler2D u_vel_tex;
out vec3 out_norm;
out vec2 out_tex;
in vec2 v_tex;

void main() {
  vec3 center = texture(u_pos_tex, v_tex).rgb;
  vec3 right  = textureOffset(u_pos_tex, v_tex, ivec2(1,  0)).rgb;
  vec3 top    = textureOffset(u_pos_tex, v_tex, ivec2(0, -1)).rgb;

#if 1
  vec3 dx = right - center;
  vec3 dy = top - center;
#else
  vec3 dx = center - right;
  vec3 dy = center - top;
#endif

  out_norm = normalize(cross(dx, dy));
  out_tex = v_tex;
}

//vec3 left   = textureOffset(u_pos_tex, v_tex, vec2(-1.0,  0.0)).rgb;
//vec3 bottom = textureOffset(u_pos_tex, v_tex, vec2( 0.0,  1.0)).rgb;
//vec3 dx = left - right;
//vec3 dy = top - bottom;

NAT Types This is so exciting, in this article I dive into some of the different ways a NAT device translates addresses which is important for peer-to-peer connections.
Building Cabinets In this post I dive into the design and construction of a cabinet with an interact LED strip. I also explain how I dynamically change the colors of the LEDs over TCP/UDP.
Compiling GStreamer from source on Windows How to compile GStreamer on Windows from Source using Visual Studio 2019 and the meson build system.
Debugging CMake Issues In this post I explain a process you can follow to debug issues with CMake by focusing on a specific target and making the output verbose.
Dual Boot Arch Linux and Windows 10 How to install Arch Linux and Windows 10 Pro as dual boot. A step by step tutorial how to create bootable installers, partition and setup a dual boot menu.
Mindset Updated Edition, Carol S. Dweck (Book Notes) Paragraphs I marked from the book "Mindset" from Carol S. Dweck.
How to setup a self-hosted Unifi NVR with Arch Linux A step by step HOW-TO that explain show to setup a Unifi Video Controller with an NFS share with Arch Linux.
Blender 2.8 How to use Transparent Textures Follow this node setup when you want to use an image with transparency as a "sticker".
Compiling FFmpeg with X264 on Windows 10 using MSVC A couple of steps to compile FFmpeg on Windows using MSVC.
Blender 2.8 OpenGL Buffer Exporter The following Blender script creates a [name].h and [name].cpp for the selected object and stores the positions, normals and UVs.
Blender 2.8 Baking lightmaps Light maps are a cheap way to add a lot of realism to you static scenes and have been used forever.
Blender 2.8 Tips and Tricks Use Environment Map only for reflections; create a floor plane for a Product Render, diffuse texture for roughness and more!
Setting up a Bluetooth Headset on Arch Linux Learn how to setup a Sennheiser PXC 550 Bluetooth headset on Arch Linux.
Compiling x264 on Windows with MSVC Compile the excellent x264 source on Windows using MSYS2 and MSVC.
C/C++ Snippets Is a number divisible by four?
Reading Chunks from a Buffer Some thoughts on reading bytes from a file; handy for reading NALs.
Handy Bash Commands Bash scripts: removing white space, lowercase filenames, backup using tar, etc.
Building a zero copy parser Simple solution to parse data in a pretty performant way. Used this for a RTSP protocol parser.
Kalman Filter A very simple yet powerful filter which works great when you have to smooth noisy data. Used for the Nike Rise 2.0 project.
Saving pixel data using libpng Do you have raw RGBA data that you want to save? Use this snippet to save it into a PNG file.
Compile Apache, PHP and MySQL on Mac 10.10 Setup you own PHP, MySQL and Apache and with virtual document roots.
Fast Pixel Transfers with Pixel Buffer Objects Using Pixel Buffer Objects (PBO) for fast asynchronous data transfers and OpenGL.
High Resolution Timer function in C/C++ Wait...... wait.. fast high resolution timer funtions (Windows, Linux, Mac)
Rendering text with Pango, Cairo and Freetype My never ending obsession with font rendering. A complex beast to do well. Use Pango and FreeType for the heavy lifting.
Fast OpenGL blur shader Make things look blurry ... and fast using this OpenGL blur shader.
Spherical Environment Mapping with OpenGL An old trick to get great lighting effects using Environment Maps and OpenGL.
Using OpenSSL with memory BIOs OpenSSL is a great library with lots of abstractions. In this post I discuss how to break some of these abstractions and use your own memory buffers.
Attributeless Vertex Shader with OpenGL A simple way to render a fullscreen quad without a vertex buffer with OpenGL.
Circular Image Selector Some thoughts on a different way to select images from a huge collection in a compact UI.
Decoding H264 and YUV420P playback Using libav to demux and playback with OpenGL.
Fast Fourier Transform Analyse your audio using the Fastest Fourier Transform in the West.
OpenGL Rim Shader Pretty glowy edges using a GLSL rim shader.
Rendering The Depth Buffer Render the non-linear OpenGL Depth Buffer.
Delaunay Triangulation Do you need to triangulate some shape: use the “Triangle” library.
RapidXML RapidXML is a versatile and fast XML parser with a simple API. Check out these examples.
Git Snippets Some simple GIT snippets; added here to remind myself.
Basic Shading With OpenGL A couple of basic GLSL shaders with explanation.
Open Source Libraries For Creative Coding Collection of great open source libraries for you creative programming projects.
Bouncing particle effect Snippet that can be used to create a bouncy particle effect; basic, effective, simple but nice.
OpenGL Instanced Rendering Want to render thousands and thousands of objects? Use OpenGL instanced rendering. The solution...the only solution.
Mapping a texture on a disc Ever heard about projective interpolation related to texture mapping? Learn about this intertesting issue with OpenGL and texture mapping.
Download HTML page using CURL When you want a quick solution to perform a HTTP(S) request CURL is always a quick an simple solution. Check out this example code.
Height Field Simulation on GPU Although not a Navier-Stokes implementation ... still a very nice and enjoyable effect.
OpenCV Optical Flow: when doing anything with tracking you've probably heard of it. See this simple example code using OpenCV and OpenGL.
Some notes on OpenGL FBOs and Depth Testing, using different Attachment Points, a YUV420p shader, ...
Math Meaning of the Dot Product in 3D graphics, calculating a perpendicular vector using Sam Hocevar's solution, orientation matrix and more.
Gists to remember Some gists that I want to remember, often use, etc...
Reverse SSH Do you want to login, into a remote PC but the remote PC is behind a firewall? Then use this simple reverse SSH trick which doesn't require changing your firewall rules.
Working Set Having issues with your compiler? Or during linking? Check these common issues and their solutions. I also list several tools that you can use to get a some useful info.
Consumer + Producer model with libuv Example of a common Multi Threaded Consumer/Producer Model using LibUV.
Parsing binary data Learn about the basic of a binary protocol and how to create one easily yourself.
C++ file operation snippets Reading a file into a string, vector, checking the file size, change to a position, etc. A collection of C++ file operation snippets.
Importance of blur with image gradients Do you want to experiment with OpenGL and aligning Brush Strokes along Image Gradients? Then check out this post about the importance of blurring.
Real-time oil painting with openGL Code snippet for fake "oil painting" effect with OpenGL using instanced rendering.
x264 encoder Basic example on how to use libx264 to encode image data using libav
Generative helix with openGL Screenshots of a project I worked on with that generates a DNA helix.
Mini test with vector field Screenshots while experimenting with a vector field; nothing much to see here.
Protractor gesture recognizer Testing the amazing One Dollar $1 gesture recognizer. The simplest and very good gesture recognizer.
Hair simulation Example code that implements the "Fast Simulation of Inextensible Hair and Fur" paper from M. Müller, T.Y. Kim and N.Chentanez.
Some glitch screenshots Glitch screenshots.
Working on video installation Screenshots of some experiments of a video installation.
Generative meshes I enjoy creating physics based simulations and render them on high res. Here are some experiments I did a time ago.
Converting video/audio using avconv Examples that show you how to use avconv to manipulate video and audio files.
Auto start terminal app on mac Automatically start you application whe Mac boots and make sure that it restarts your app when it exists. Handy for interactive installations.
Export blender object to simple file format Export the selected object in Blender into a .h and .cpp file that prepresents the buffer.
